Lincat CO223T Convector Touch Commercial Convection Oven – 96 Litre, 13A Plug-In, Touchscreen Control

The British-made Lincat CO223T Convector Touch is a professional commercial convection oven combining a generous 96-litre cooking capacity, intuitive touchscreen controls and the convenience of a standard UK 13A electrical connection.

Designed for busy cafés, pubs, restaurants, hotels, schools, care homes and commercial kitchens, this versatile countertop oven is ideal for roasting, baking, braising and reheating a wide variety of dishes.

Unlike many commercial ovens requiring high-current electrical supplies, the CO223T operates from a standard 13A socket. Its advanced touchscreen controls, programmable cooking stages and five levels of humidity injection provide greater flexibility than a conventional manually controlled convection oven.

Includes typical 2–3 working day Mainland UK courier delivery – shipped directly from the manufacturer.

13A Plug-In – No Hardwiring Required

One of the biggest advantages of the CO223T is its straightforward electrical connection.

The oven operates from a standard 230V single-phase electrical supply and comes with a UK 13A three-pin plug.

* Power – 3kW / 3000W
* Voltage – 230V
* Phase – Single phase
* Electrical Load – 13A
* Connection – Standard UK 13A plug
* Hardwiring Required – No
* Three-Phase Supply Required – No
* Dedicated Electrical Circuit – Required

This makes the CO223T particularly suitable for establishments looking to introduce professional convection cooking without installing a three-phase electrical supply.

Touchscreen Control & Programmable Cooking

The CO223T features an intuitive electronic touchscreen, allowing operators to control cooking temperature, time, fan speed and humidity injection.

Up to 24 cooking programmes can be stored, each incorporating up to four individually adjustable cooking stages.

This allows frequently prepared dishes to be cooked consistently, reducing operator involvement and helping achieve repeatable results during busy service.

A traffic-light-style status display makes it easy to monitor the oven's progress at a glance.

Five Levels of Humidity Injection

Unlike the manually controlled CO223M, the CO223T features five adjustable levels of humidity injection.

This provides additional flexibility when cooking products that benefit from controlled moisture, helping reduce excessive drying and improve cooking results.

The humidity injection system requires a mains water connection.

A suitable water treatment filter is recommended to help protect the oven from limescale, particularly in hard-water areas.

Two-Speed, Bi-Directional Fan

The electronically controlled fan offers two speeds and automatically changes direction to promote even heat distribution throughout the cooking chamber.

The slower fan speed is particularly useful for delicate products such as pastries and meringues, while the higher speed is suitable for general roasting, baking and reheating.

Generous 96-Litre Cooking Capacity

Despite its countertop design, the CO223T provides a substantial 96-litre cooking chamber.

It accommodates:

* 2 x GN1/1 Gastronorm containers
* 2 x 600 x 400mm Euronorm trays
* 2 x 660 x 460mm baking sheets

Two wire shelves are included as standard.

The oven features a drop-down door with viewing glass, internal lighting and removable shelf guides to assist with cleaning.

Compatible Floor Stand – Sold Separately

The CO223T can be installed on a suitable commercial worktop or combined with a dedicated Lincat floor stand.

* CO200/FS – Lincat Convector Floor Stand, 810mm width, compatible with the CO223T. Six-runner configuration specified; please confirm the stand version when ordering.

The stand provides a convenient floor-standing arrangement with additional storage beneath the oven.

Please note that the CO200/FS floor stand is an optional accessory and is SOLD SEPARATELY. It is not included with the oven.

Key Features -

* British-made Lincat Convector Touch commercial convection oven
* Generous 96-litre cooking capacity
* Standard UK 13A plug-in electrical connection
* 3kW heating power
* 230V single-phase supply
* No hardwiring or three-phase supply required
* Intuitive electronic touchscreen controls
* Up to 24 programmable cooking programmes
* Up to four individually adjustable cooking stages
* Adjustable temperature, time, fan speed and humidity for each cooking stage
* Five levels of humidity injection
* Traffic-light-style cooking status display
* Electronically controlled two-speed fan
* Bi-directional airflow for even heat distribution
* Adjustable cooking temperature from 30°C to 260°C
* Electronic countdown timer and audible buzzer
* Flashing oven lamps indicate completion of the cooking cycle
* Suitable for roasting, baking, braising and reheating
* Capacity for 2 x GN1/1 Gastronorm containers
* Compatible with 600 x 400mm Euronorm trays
* Two wire shelves included
* Stainless steel cooking chamber
* Drop-down door with viewing glass
* Interior oven lighting
* Removable shelf guides for easier cleaning
* USB port
* Requires a mains water connection for humidity injection
* No drain connection required
* Compatible CO200/FS floor stand available separately
* 2-year Lincat parts and labour warranty

Technical Specification -

* Manufacturer – Lincat
* Model – CO223T
* Range – Convector Touch
* Product Type – Commercial electric countertop convection oven
* Oven Capacity – 96 litres
* Power – 3kW / 3000W
* Voltage – 230V
* Phase – Single phase
* Electrical Load – 13A
* Electrical Connection – Standard UK 13A three-pin plug
* Dedicated Electrical Circuit Required – Yes
* Hardwiring Required – No
* Three-Phase Supply Required – No
* Temperature Range – 30°C to 260°C
* Temperature Control – Electronic touchscreen
* Programmable Cooking – Yes
* Cooking Programmes – 24
* Cooking Stages – Up to 4 per programme
* Humidity Injection – 5 adjustable levels
* Fan – Two-speed, bi-directional
* Gastronorm Capacity – 2 x GN1/1
* Euronorm Capacity – 2 x 600 x 400mm
* Baking Sheet Capacity – 2 x 660 x 460mm
* Shelves Included – 2 wire shelves
* Shelf Dimensions – 660(W) x 425(D)mm
* Internal Cooking Chamber Dimensions – 690(W) x 470(D) x 308(H)mm
* External Dimensions – 810(W) x 850(D) x 645(H)mm
* Net Weight – 80kg (current manufacturer specification)
* Shipping Weight – 88kg
* Water Connection – 3/4-inch
* Water Pressure – 2 to 6 bar
* Water Treatment – Recommended
* Drain Connection Required – No
* Door – Drop-down with viewing glass
* Interior Lighting – Halogen
* Installation – Countertop or compatible floor stand
* Compatible Floor Stand – CO200/FS, sold separately
* Country of Manufacture – United Kingdom
* Warranty – 2 years parts and labour
